Vectors, Matrices, Least Squares by Boyd, Vanderberghe (2018)

Python & Julia notebooks are available here

Part I : Vectors

1. Vectors

• A vector is an ordered, finite list of numbers.

  • In coding, it is usually represented by arrays or lists (and not tuples).

• Vector notations can wildly differ among authors, so caution is advised.

• Some notations don’t distinguish between a 1-vector and scalars (numbers). In coding, they’re in different data structures.

• There’s vectors like zero, unit, one, sparse vectors.

• Adding/subtracting vectors is different from stacking their contents.

• The inner product (or dot product) of n-vectors $x$ and $y$ is written as $x^Ty$

• Sparse vectors reduce computation time; both Python and Julia have them as dedicated data structures.

2. Linear Functions

• Functions that take in vectors are simply written as $f(x)$ with $x$ as an n-vector.

• Example: inner product function $f(x) = a^Tx$

  • Can be seen as a weighted sum of elements of $x$

• A linear function $f(x)$ is when:

  • $f(ax) = af(x)$ for scalar $a$ and n-vector $x$

  • $f(x+y) = f(x) + f(y)$ for n-vectors $x$ and $y$

• Example: mean() is a linear function, max() is not, median() is not.

• A differentiable function (doesn't need to be linear) can be approached by a linear function with Taylor approximation.

• Regression can be written with vectors as $f(x) = x^T\beta + v$ (an affine function)

3. Norm and Distance

• The (Euclidean) norm of an n-vector $x$ is $||x|| = \sqrt{x_{1}^2+x_{2}^2+...+x_{n}^2}$

  • Also written as $||x|| = \sqrt{x^Tx}$

  • Norm is more general than “length”.

• The triangle inequality for norms: $||x+y|| \leq ||x|| + ||y||$

• The RMS of a vector can be calculated by its norm: $rms(x) = \frac{||x||}{\sqrt{n}}$

• Chebyshev’s inequality states that the number of entries of an n-vector $x$ with absolute value $\geq a$ is no more than $\frac{||x||^2}{a^2}$

  • Chebyshev’s inequality (stats version): the percentage of entries of an n-vector $x-\mu$ with absolute value $\geq k\sigma$ is no more than $\frac{1}{n}\frac{||x-\mu||^2}{(k\sigma)^2} = \frac{1}{k^2}$

• The (Euclidean) distance of two vectors $x$ and $y$ is $dist(x) = ||x-y||$

• Average, RMS, and standard deviation: $rms(x)^2 = avg(x)^2 + std(x)^2$

• We can standardize a vector by subtracting its $avg()$ and dividing by $std()$, these are called z-scores.

• The angle between two vectors $x$ and $y$ is $\theta = arccos(\frac{a^Tb}{||a||\, ||b||})$

• The correlation coefficient between two vectors $x$ and $y$ is $\rho = \frac{(x-avg(x))^T(y-avg(y))}{||x-avg(x)||\,||y-avg(y)||}$

4. Clustering

• Clustering outside of simple cases:

  • In almost all applications $n$ is larger than 2 (we can’t just scatterplot the values).

  • There will be some or even many points between clusters.

  • In real examples the best number of $k$ clusters will be less clear.

• Formalizing a clustering objective:

  • All vectors $x_i$ get clustered into clusters $c$ , where $c_{i}$ is the group where $x_i$ is assigned to.

  • With each cluster $c$ there is a group representative $z_{c_{i}}$ (doesn’t need to be one of $x_i$) which is close to each vectors $x_{i}$ in that group (small distance $||x_{i} - z_{c_{i}}||$ ).

  • $J^{clust}$ = mean squared distance of each vector to their group representative

• Optimal clustering is minimizing objective $J^{clust}$, but this is computationally impractical outside of small problems.

• $k$-means is suboptimal but finds very good clustering (close to smallest $J^{clust}$)

  • Algorithm: given vectors $x_i$ and initial list of group representatives $z_{c_{i}}$ , repeat steps 1 & 2 until convergence

    1. Given $z_{c_{i}}$ , find best cluster assignments for each $x_i$

    2. For each cluster, set each group representative $z_{c_{i}}$ into mean of vectors in group

  • The algorithm is a heuristic. Different initial representatives can result in different clustering and final value of $J^{clust}$

  • The resulting representatives $z_1,…,z_k$ are quite interpretable. Example: if 4th part of vector is age, then $(z_3)_4$ = 37.8 tells us average age of group 3 is 37.8

5. Linear Independence

• A collection of n-vectors $a_1,a_2,...,a_k$ is linearly independent if $\sum_{i=1}^{k}\beta_ia_i = 0$ only holds up for $\beta_1 = \beta_2 = ... = \beta_k = 0$.

• Like linear dependence, linear independence is an attribute of a collection of vectors, not individual vectors.

• Independence-dimension inequality: A linearly independent collection of n-vectors can have at most $n$ elements.

  • A collection of $n$ linearly independent n-vectors is called a basis.

• A collection of n-vectors $a_1,a_2,...,a_k$ is orthonormal if each vector pair is orthogonal ($a_i \perp a_j$ for $i \neq j$) and $||a_i|| = 1$

• Gram-Schmidt algorithm can be used to determine if a collection of vectors is linearly independent.

  • It finds the first vector $a_j$ that is a linear combination of previous vectors $a_1,…, a_{j-1}$

  • Step 1: Orthogonalization: $\tilde{q_i} = a_i - (q^T_1 a_i)q_1 - … - (q^T_{i-1} a_i)q_{i-1}$

  • Step 2: Test for linear dependence: if $\tilde{q_i} = 0$ , quit.

  • Step 3: Normalization: $q_i = \tilde{q_i}/||\tilde{q_i}||$

Part II : Matrices

coming soon...

Part III : Least Squares
